[CA-PMP122305120] Multiplus-II 12/3000/120-50 120V, Inverter / Charger
[CA-LYN020102000] Lynx Power In

MPPT, Smart Solar 150/85-TR VE.


975.80 975.80 975.8000000000001 CAD 975.80
Not Available For Sale

    This combination does not exist.

    Request Availability and Alternates


    (0 review)


    The MPPT controller is a sophisticated way to harvest the maximum power from a solar array. It adjusts its input voltage to the optimal level for maximum power production and decouples the solar array voltage from the battery voltage. The model can accept a maximum 150 Volt input voltage and has a maximum output current of 85 Amps at 12,24,36 or 48 volts

    • For 12, 24, 36 or 48 volt systems
    • Max PV Power at 48 Volts: 4900 Watts
    • Max PV Power at 24 Volts: 2400 Watts
    • Max PV Power at 12 Volts: 1200 Watts
    • Outstanding conversion efficiency, max efficiency is 98%
    • No cooling fan.
    • Flexible charge algorithm programmable via Bluetooth
    • Extensive electronic protection
    • Over-temperature protection and power derating when temperature is high.
    • PV short circuit and PV reverse polarity protection.
    • PV reverse current protection.
    • Internal temperature sensor included, can be networked to an external temp sensor (BMV 712, SmartShunt or Smart Battery Sense)
